Why Tube Settlers ?
Tube settlers offer an inexpensive method of upgrading existing water treatment plant clarifiers and sedimentation basins to improve performance.
They can also reduce the tankage/footprint required in new installations or improve the performance of existing settling basins by reducing the solids loading on downstream filters.
Made of lightweight PVC, tube settlers can be easily supported with minimal structures that often incorporate the effluent trough supports.
They are available in a variety of module sizes and tube lengths to fit any tank geometry, with custom design and engineering offered by the manufacturer.

Advantages of 35mm, 50mm, 80mm Anti UV PVC Lamella Plate PP Honeycomb Tube Settler Media
The advantages of tube settlers can be applied to new or existing clarifiers/basins of any size:
* Clarifiers/basins equipped with tube settlers can operate at 2 to 4 times the normal rate of clarifiers/basins without tube
settlers.
* It is possible to cut coagulant dosage by up to half while maintaining a lower influent turbidity to the treatment plant
filters.
* Less filter backwashing equates to significant operating cost savings for both water and electricity.
* New installations using tube settlers can be designed smaller because of increased flow capability.
* Flow of existing water treatment plants can be increased through the addition of tube settlers.
* Tube settlers increase allowable flow capacity by expanding settling capacity and increasing the solids removal rate in settling tanks.
