FS7 Flame Detector

FS7 Flame Detector

The FS7 Flame Detector provides an intelligent two-stage response to semiconductor wet bench fires:

Stage 1: Alert. This is the first-stage response to a small fire with a heat energy output of 3 kW (the equivalent of a 4-inch diameter polypropylene pool fire). This allows time for the fire to self-extinguish.

The FS7-2173 is used with the FS7-130-SX Controller or Control Panel FSWB. Controller and Control Panel supply power to detectors monitor the status of all detectors and communicate with the detectors via the digital RS-485 communication channel. This allows for fast and easy connections eliminating wiring problems. Each detector can store up to six time and date stamped FirePics™ (pre-event multi-spectral sensor array data) in non-volatile memory. FirePics™ and event histories can be retrieved from the controller or control panel.

Additional Features and Benefits

• Multi-Spectral digital electro-optical radiant energy infrared fire detector
• Unique two-stage fire detection response
• Immune to false alarm sources
• NOT affected by absorbing smoke, gasses or chemical vapors
• NOT sensitive to background radiant energy from electric heaters and ovens
• Detects hydrocarbon and non-hydrocarbon fires
• Rugged leak-proof, heat-sealed, acid-resistant, injection-molded polypropylene housing
• Wide 120° field-of-view
• Digital communication with RS-485 interface
• FirePic™: time and date-stamped digital fire signatures
• Built-in detector automatic self test
• Unitzed model design for stand-alone operatio
