Signalpoint Flammable and Toxic Gas Detector

Signalpoint Flammable

The Signalpoint range of flammable, toxic and Oxygen gas detectors offers a low cost solution to indoor gas monitoring.

Product Overview:

Supplied with an integral pre-wired junction box, the detector can be installed using conduit or cable and glands depending on individual site standards.

Two basic arrangements are provided. Flammable detectors offer mV bridge output for use with dedicated gas control systems (such as Unipoint) and are certified under ATEX for use in potentially explosive atmospheres. Toxic and Oxygen detectors are designed for use in non-explosive atmospheres.

They are 2 wire 4-20mA loop powered and can be used with PLC or dedicated gas control systems.

Toxic and Oxygen versions of Signalpoint also provide a local LED indication of their status: periodic green flash (OK), flashing amber (warning) and flashing red (alarm). Seconds count and so the front-end sensor design ensures fast speed of response even with ‘sticky’ gases.

Easy installation is provided for. The junction box includes ‘hidden’ mounting for wall and ceiling fixings. The hinged lid of the junction box ensures both hands are free to complete electrical connections via the M20 clearance cable/conduit entry.

Additional Features and Benefits:

One-Stop Shop:

• Flammable, toxic and Oxygen versions available
• IP54 as standard
• Suitable for indoor use

Proven Sensor Technology:

• Surecell™ electrochemical sensors
• Poison resistant catalytic bead
• Fast and reliable

Combustible Version:

• ATEX hazardous area approval
• Performance to EN50054
• Typical 5 year operational life

Toxic and Oxygen Versions:

• Indoor non hazardous area use
• Local LED indication of status (operation, A1 and A2)
• Performance to EN45544*
• Typical 2 year operational life * H2S version only

See more…….
